N60D1-STR Waterproof Dual-Beam 2 Inch LED Fog Lights Projector

The NVEL N60D1-STR is a compact 2-inch waterproof dual-beam LED fog light projector designed for compatible automotive lighting retrofit applications. Its direct-projection optical design provides separate low-beam and high-beam functions in a compact housing.The 35W low beam is specified at 1,600 lumens ±10%, with an illuminance of 450 lux ±10% at 10 meters. The 60W high beam provides a specified output of 2,400 lumens ±10% and 1,200 lux ±10% at 10 meters.With a 6,000K ±500K color temperature, an IP67-rated design and support for standard 2-inch metal or vehicle-specific plastic retrofit brackets, the N60D1-STR offers a practical lighting option for automotive distributors, retrofit specialists and wholesale buyers.Final vehicle fitment, bracket selection and electrical compatibility should be verified before installation.

Compact 2-Inch Projector Design

The N60D1-STR features a compact optical module intended for space-conscious automotive retrofit installations. Buyers should confirm the complete module dimensions and mounting clearance before ordering.

35W Low Beam & 60W High Beam

The dual-beam design provides a 35W low-beam function and a 60W high-beam function. The supplied specifications list 1,600 lumens for low beam and 2,400 lumens for high beam, both with a ±10% tolerance.

Controlled Beam Distribution

The direct-projection optical configuration is designed to provide a defined low-beam pattern and focused high-beam illumination. Actual road performance depends on installation, alignment and vehicle-specific operating conditions.

IP67-Rated Protection

The product is specified with an IP67 ingress-protection rating, supporting use in environments where dust and water exposure are important design considerations.

DISCOVER NVEL →
SHARE PRODUCT

Technical Specifications for 2 Inch LED Fog Lights

Specification	Value	Specification	Value
Model	N60D1-STR	Beam Type	Dual Beam
Product Type	2-Inch Waterproof Direct Projection Lens	Low / High Beam Power	35W / 60W
Low / High Beam Luminous Flux	1,600 lm ±10% / 2,400 lm ±10%	Low / High Beam Illuminance	450 lx ±10% @ 10m / 1,200 lx ±10% @ 10m
Color Temperature	6,000K ±500K	Waterproof Rating	IP67 (manufacturer-specified)
Overall Height	92 mm	Body Height	76 mm
Labeled Diameter	Ø59 mm	Labeled Front Width	69 mm
Mounting Options	Standard 2-Inch Metal Bracket / Vehicle-Specific Plastic Retrofit Bracket	Power Rating Note	Separate beam ratings; not a combined 95W rating

N60D1-STR 2 Inch LED Fog Lights Features & Applications

Flexible Mounting Options: The N60D1-STR supports installation planning with standard 2-inch metal brackets and vehicle-specific plastic retrofit brackets. Mounting compatibility should be checked against the actual vehicle and bracket dimensions. Verify installation space, bracket dimensions, electrical interfaces and applicable local regulations before use. IP67 is the manufacturer-specified rating; independent certification has not been verified.

N60D1-STR 2-inch waterproof dual-beam projector product overview

N60D1-STR specifications showing 35W low beam, 60W high beam, luminous flux and illuminance

FAQ

What is the difference between the low beam and high beam?

The direct-projection design provides separate low-beam and high-beam functions. Low beam is specified at 35W and high beam at 60W. Actual beam performance depends on installation and alignment.

What are the N60D1-STR’s actual power ratings?

The specified ratings are 35W for low beam and 60W for high beam. These are separate beam ratings and must not be added together as a simultaneous 95W rating.

What are the specified luminous outputs and illuminance values?

Low beam: 1,600 lm ±10% and 450 lx ±10% at 10m. High beam: 2,400 lm ±10% and 1,200 lx ±10% at 10m. These are manufacturer-supplied specifications.

What is the color temperature?

The specified color temperature is 6,000K ±500K.

Is the N60D1-STR IP67-rated?

The manufacturer specifies an IP67 ingress-protection rating. Independent IP67 certification has not been verified.

What mounting brackets are supported?

The specified mounting options are standard 2-inch metal brackets and vehicle-specific plastic retrofit brackets. Confirm bracket dimensions and mounting clearance before ordering.

Is it compatible with every vehicle?

No universal vehicle compatibility is claimed. Verify installation space, bracket dimensions, electrical interfaces and applicable local regulations before installation.
